Ü Data Queue
·
It is used for making
asynchronous communication between the two jobs. If we are sending data from
one job to another using data queue using QSNDDTAQ API, but at that time the
receiver job is not active, then the data will be there in the queue and
whenever the receiver job becomes active, it retrieves the data using the
QRCVDTAQ API.
·
It facilitates fastest
communication compared to when we use other things to communicate like
dataarea, message queue or database files.
·
It can yet be used for
synchronous communication also or within the same job.
·
We use APIs to make
communication e.g. QSNDDTAQ, QRCVDTAQ.
·
The content of the data queue
is messages in free format.
·
The messages on the data queue
is stored in *FIFO, *LIFO or *KEYED. *KEYED means the messages can be retrieved
using key value associated with the messages. In case of *KEYED we need to
mention key length also.
·
First create the data queue by
using CRTDAQ command
·
Data query is nothing but a
queue in which are program can send a data and other program or the same
program can receive the program. QSNDDTAQ is stored in QSYS.
·
We can create data queue on
local system or on remote system by making the data queue type as *DDM. By
default it will be *STD. In case of DDM data queue, we need to mention Remote
data queue name(RMTDTAQ) and remote system name(RMTLOCNAME) also as parameter.
·
QSNDDTAQ
By using this command sent data same / another program.
QSNDDTAQ PARM
(QUEUE-NAME LIB &LEN &DAT)
·
QRCVDTAQ
By using this command receive data same /another program
QRCVDTAQ PARM (QUEUE-NAME LIB &LEN &DAT
&WAIT)
Example
Step
(1): First of all create a data queue as below:
CRTDTAQ
DTAQ(DTAQ000) TYPE(*STD) MAXLEN(300) TEXT('DATA QUEUE DTAQ000')
Step
(2): Now we write one RPG program to write data to
this data queue.
Columns . . . : 1 100 Browse IROBO1/QRPGLESRC
SEU==> DTAQ00_RPG
FMT D .....DName+++++++++++ETDsFrom+++To/L+++IDc.Keywords+++++++++++Comments+++++++++++
*************** Beginning of data ***********************************************
0001.00 DQueue S 10A INZ('DTAQ000')
0002.00 DLib S 10A INZ('IROBO1')
0003.00 DLen S 5 0 INZ(100)
0004.00 DData DS
0005.00 DSYSNAME 8 INZ('SYS00001')
0006.00 DFILLER1 2 INZ(' ')
0007.00 DDOMAIN 5 INZ('AS400')
0008.00 DFILLER2 2 INZ(' ')
0009.00 DADDRESS 30 INZ('SYS00001.AS400.NET')
0010.00 DCMDDSC S 256A
0011.00 DCMDLEN S 15P 5
0012.00
0013.00 *-------------------------------------------------------------
0014.00 * Main section of the program
0015.00 *-------------------------------------------------------------
0016.00 C EXSR CLRDTAQ
0017.00 C EXSR SNDDATA
0018.00 C SETON LR
0019.00 *
0020.00 *
0021.00 *-------------------------------------------------------------
0022.00 * Call the API to Send the DATA to the DATAQ
0023.00 *-------------------------------------------------------------
0024.00 C SNDDATA Begsr
0025.00 *
0026.00 *
0027.00 C call 'QSNDDTAQ'
0028.00 C Parm Queue
0029.00 C Parm Lib
0030.00 C Parm Len
0031.00 C Parm Data
0032.00 *
0033.00 C EndSr
0034.00
0035.00 *---------------------------------------------------------------------
0036.00 * Clear DATAQ
0037.00 *---------------------------------------------------------------------
0038.00 C CLRDTAQ BegSr
0039.00 *
0040.00 C Eval CMDDSC='DLTDTAQ DTAQ(IROBO1/DTAQ000)'
0041.00
0042.00 C Eval CMDLEN=%len(%trim(CMDDSC))
0043.00 C CALL 'QCMDEXC'
0044.00 C PARM CMDDSC
0045.00 C PARM CMDLEN
0046.00 *
0047.00 C Eval CMDDSC='CRTDTAQ DTAQ(IROBO1/DTAQ000) +
0048.00 C MAXLEN(300)'
0049.00 C
0050.00 C Eval CMDLEN=%len(%trim(CMDDSC))
0051.00 C CALL 'QCMDEXC'
0052.00 C PARM CMDDSC
0053.00 C PARM CMDLEN
0054.00 *
0055.00 C EndSr
****************** End of data ***********************************************
Step
(3): Now we write one RPG program to retrieve data
from the data queue.
Columns . . . : 1 100 Browse IROBO1/QRPGLESRC
SEU==> DTAQ01_RPG
FMT D .....DName+++++++++++ETDsFrom+++To/L+++IDc.Keywords++++++++++++Comments++++++++++++
*************** Beginning of data ************************************************
0001.00 DQueue S 10A INZ('DTAQ000')
0002.00 DLib S 10A INZ('IROBO1')
0003.00 DLen S 5 0 INZ(100)
0004.00 DData DS
0005.00 DSYSNAME 8
0006.00 DDOMAIN 5
0007.00 DADDRESS 30
0008.00 DWait S 5 0 INZ(0)
0009.00
0010.00 *-------------------------------------------------------------
0011.00 * Main section of the program
0012.00 *-------------------------------------------------------------
0013.00 C EXSR RCVDATA
0014.00 C DATA DSPLY
0015.00 C SETON LR
0016.00 *
0017.00 *
0018.00 *---------------------------------------------------------------------
0019.00 * Call the API to recive the DATA form the DATAQ
0020.00 *---------------------------------------------------------------------
0021.00 C RCVDATA Begsr
0022.00 *
0023.00 C Call 'QRCVDTAQ'
0024.00 C Parm Queue
0025.00 C Parm Lib
0026.00 C Parm Len
0027.00 C Parm Data
0028.00 C Parm Wait
0029.00 *
0030.00 C EndSr
0031.00
****************** End of data ****************************************************
OUTPUT
DSPLY
SYS00001 AS400 SYS00001.AS400.NET
